Product Features:
Integrated two-wire transmitter, no moving parts
Side-wall mounting is convenient for special working conditions
4 ½ digit LCD display
Two-wire density meter
Digital output control
Online remote recalibration
Suitable for flowing and stationary liquids
Stainless steel or other materials for the liquid receiving part, hygienic and corrosion resistant.
Intrinsically safe and explosion-proof
Technical parameters:
Output signal: 2-wire 4-20mA
Power supply: 24VDC
Local display: 4 ½ digits or 5-bit female liquid crystal display
Accuracy: 0.1% (at 20℃)
Repeatability: 0.2%
Explosion-proof performance: explosion-proof water discharge sealed shell, intrinsically safe explosion-proof
Temperature range: Ambient: -40~85℃; Process: -20~150℃ Storage: -40~100℃; Digital display: -10~60℃.
Starting time: 5 seconds after the power supply is connected to start
Static pressure range: 7Mpa
Humidity range: 0~100%RH
Electrical Connection: M20*1.5
Process connection: Flange connection or quick-fit chuck (sanitary)
Receiving material: 316L stainless steel; HC22; PTFE, etc. (can be customized according to the actual working conditions)
Installation: vertical installation or tank side mounted
Medium flow direction: bottom-up or static measurement
Protection class: IP65
Shell material: aluminum alloy
